| Series | AMPSEAL 16 Series |
|---|---|
| Brand | Deutsch, TE Connectivity |
| Part Number | 2138846-2 |
| Receptacle Contact Housing/Pin Contact Housing/PCB Header | Pin Contact Housing |
| Flange/In-line/PCB Mount | Flange |
| keyed | Yes |
| Shape | Rectangular |
| Material | Plastic |
| Connector Style | Pin Contact Housing |
| Insulation | (#12).111-.161 [2.82-4.09], (#16).066-.109 [1.68-2.77] |
| Wire Size | 10, 12, 14, 16, 18, 20 |
| Holds Pin/Receptacle Contact | Pin |
| Color | Brown |
Contacts
Mating Connectors
Required Components
this product has no mating Required components products
Accessories
Description
Details
2138846-2
Drawings
Product Drawing (PDF) (862.92 KB)
Product Drawing (PDF) (862.92 KB)
CAD Files 2D DrawingВ (DXF Version 99 ZIP) (130.11 KB)
CAD Files 3D ModelВ (IGES Version 99 ZIP) (1.42 MB)
CAD Files 3D ModelВ (STEP Version 99 ZIP) (714.77 KB)
Customer View Model (PDF) (599.51 KB)
Customer View Model (PDF) (599.51 KB)
