DeutschCatalogue item
DT16-15SA-K003
Generally high availability — ask for current lead time
No. of cavities
15
Color
Purple
Connector Style
Plug
Holds Pin/Socket
Socket
Insulation
(#12).097-.158 [2.46-4.01], (#16).053-.120 [1.35-3.05]
keyed
Yes, A key
Additional information
| No. of cavities | 15 |
| Color | Purple |
| Connector Style | Plug |
| Holds Pin/Socket | Socket |
| Insulation | (#12).097-.158 [2.46-4.01], (#16).053-.120 [1.35-3.05] |
| keyed | Yes, A key |
| Material | Plastic |
| Modification | Enhanced Seal Retention, End Cap |
| Series | DT Series |
| Shape | Rectangular |
| Wire Size | 10, 12, 14, 16, 18, 20 |
Required components
N/A
Accessories
Drawings
Customer View Model (PDF)3D_CVM_CVM_DT16-15SA-K003_99_c-dt16-15sa-k003-99-3d.pdfProduct Drawing (PDF)ENG_CD_DT16-15SX-K003_E.pdfCAD Files 2D Drawing (DXF Version 99 ZIP)ENG_CVM_CVM_DT16-15SA-K003_99_c-dt16-15sa-k003-99.2d_dxf.zipCAD Files 3D Model (IGES Version 99 ZIP)ENG_CVM_CVM_DT16-15SA-K003_99_c-dt16-15sa-k003-99.3d_igs.zipCAD Files 3D Model (STEP Version 99 ZIP)ENG_CVM_CVM_DT16-15SA-K003_99_c-dt16-15sa-k003-99.3d_stp.zip
About the manufacturer
DEUTSCHDEUTSCH is TE Connectivity's family of sealed connectors, the global benchmark for harsh-environment electrical connections. The DT, DTM, DTP, and AT series are specified in agriculture, construction, military, marine, and heavy automotive applications where vibration, moisture, and contamination resistance are critical.
