Description
Details
Specifications
- Actuation: Pneumatic
- Cooling System: Air
- Data Interface: USB, Ethernet
- Frequency: 20kHz
- Input Power: 200-250V, 50/60 Hz
- Output Power: 4000W
- Overall Dimensions: H227mm x W89mm x L577mm
- Pneumatics Type: 5.5 bar (80 psi) clean, dry air
- Special Feature: Password protection
- User Interface: Touchscreen, LCD
- Weld Modes: Time, Energy
Features
- Ergonomic, light-weight design for operation on the assembly line
- Patented, quick change tooling with multiple weld surfaces for low cost operation
- Automatic process monitoring ensures each seal falls within preset quality limits of weld power, time and final height
- Automatic tube measurement to assure proper placement of tubes within the tooling
- Weld-to-height mode to compensate for tube material variations
- Various tube sizes may be sealed in any sequence through automatic setup of weld parameters
- Parallel printer port for data collection and weld graphs
- RS232 port for computer interfacing and SPC monitoring
